データ整形に関する関数のメモ

・NAが一定割合以下の列を抽出

tmp <- df %>%
summarise_all( . %>% is.na() %>% sum) %>% #列ごとのNAの総数を集計する
gather() %>%  #縦持ちに変換
filter( value < nrow(df) *.3 ) #NAが30%以下の列を抽出

df2 <-df %>%
select(tmp\$key)

・数値だけround関数を適用して小数点切り上げ

df %>%
mutate_if(is.numeric, round, digits=0) -> df2

df %>% select(-N) %>%
spread(key=tech , value = syoricount) %>%
mutate_all(funs(ifelse(is.na(.),0,.))) %>%        #naを0に置換
mutate_if(is.numeric, round, digits=0)->df_spread #roundで切り上げ

・列V1から4文字抜き出す

df %>%
dplyr::mutate(V2 = substring(V1,1,4) ) ->df2

・列V2に対して文字の一致判定

df2 %>%
mutate(V3 = recode(V2, XXXX ="XXX1",YYYY ="YYY2" )) ->df3

・データフレーム中のNAを置換するシンプルな方法

df[is.na(df)] <- 0.01

・列名の全角カッコを半角にする

df %>%
setNames(stri_trans_nfkc(names(.))) %>%

・#分散が0以外の列を選択

data("airquality")
data_ar <- airquality
data_ar[,apply(data_ar,2,var,na.rm = TRUE) != 0]

【R言語】決定木分析の可視化パッケージ決定版？【ggparty】

決定木分析結果の可視化パッケージ【ggparty】

Rの決定木のグラフはどうしても貧弱なのが欠点でした。
その欠点を覆すべく、ggplotを使った自由度の高いパッケージggparty
ができたみたいです。 詳細はこちら。

library(rpart)
library(partykit)
library(ggplot2)
library(ggparty)

#データを用意する
tmp <- data.frame(Titanic)
df <- data.frame(
Class = rep(tmp\$Class, tmp\$Freq),
Sex = rep(tmp\$Sex, tmp\$Freq),
Age = rep(tmp\$Age, tmp\$Freq),
Survived = rep(tmp\$Survived, tmp\$Freq)
)

ct <- rpart(Survived ~ Class + Sex + Age , data = df)
pct <- as.party(ct)
pct

Model formula: Survived ~ Class + Sex + Age

Fitted party:  root |  Sex in Male | |  Age in Adult: No (n = 1667, err = 20.3%) | |  Age in Child | | |  Class in 3rd: No (n = 48, err = 27.1%) | | |  Class in 1st, 2nd: Yes (n = 16, err = 0.0%) |  Sex in Female | |  Class in 3rd: No (n = 196, err = 45.9%) | |  Class in 1st, 2nd, Crew: Yes (n = 274, err = 7.3%)

Number of inner nodes: 4 Number of terminal nodes: 5

g2 <- ggparty(pct, terminal_space = 0.5)
g2 <- g2 + geom_edge(size = 1.5)
g2 <- g2 + geom_edge_label(colour = "grey", size = 6)

##末端のノードに度数の棒グラフを追加
g2 <- g2 +   geom_node_plot(
shared_legend = FALSE,
gglist = list(geom_bar(aes(x = Survived,  #!!ct\$terms[]の意味が分からない
fill = Survived)),
theme_minimal(),
theme(legend.position = "none"))
)

##分岐点のボックスを配置
g2 <- g2 + geom_node_label(
aes(col = splitvar),
line_list = list(aes(label = paste("Node", id)),
aes(label = splitvar)),
line_gpar = list(list(
size = 12,
col = "black",
fontface = "bold"
),
list(size = 20)),
ids = "inner"
)

##末端のノードに度数のボックスを追加
g2 <- g2 + geom_node_label(
aes(label = paste0("Node ", id, ", N = ", nodesize)),
fontface = "bold",
ids = "terminal",
size = 5,
nudge_y = 0.01
)

g2

これはいい。
ほかにも

g <- ggparty(pct, terminal_space = 0.5)
g <- g + geom_edge(size = 1.5)
g <- g + geom_edge_label(colour = "grey", size = 6)
g <- g + geom_node_plot(
gglist = list(geom_bar(aes(x = "", fill = Survived), position = "fill"), theme_bw(base_size = 15)),
scales = "fixed",
id = "terminal",
shared_axis_labels = TRUE,
shared_legend = TRUE,
legend_separator = TRUE,
)
g
g <- g + geom_node_label(
aes(col = splitvar),
line_list = list(aes(label = paste("Node", id)),
aes(label = splitvar)),
line_gpar = list(list(
size = 12,
col = "black",
fontface = "bold"
),
list(size = 20)),
ids = "inner"
)
g
g <- g + geom_node_label(
aes(label = paste0("Node ", id, ", N = ", nodesize)),
fontface = "bold",
ids = "terminal",
size = 5,
nudge_y = 0.01
)
g <- g + theme(legend.position = "none")
plot(g)
ggsave(file = "決定木_度数棒グラフ.jpeg", plot = g, dpi = 800, width = 14, height =8)
